Twitter| Business Type | Manufacturer, Exporter, Supplier |
| Finishing | Polished |
| Automation Grade | Automatic |
| Usage | Industrial |
| Click to view more | |
Preferred Buyer From
| Location | Worldwide |
Product Details
Certification
CE Certified
Machine Weight
1000-2000kg
Warranty
1 Year
Country of Origin
India
Four-roller machines have a top roll, the pinching roll, and two side rolls. The flat metal plate is placed in the machine on either side and "pre-bent" on the same side. The side rolls do the work of bending. The pinching roll holds the plate.
Specifications
| VH4 MODEL |
Working Roll Length | Bending Thickness | Pre-Bending Thickness | Top Roll Diameter | Bottom Roll Diameter | Side Rollers Diameter | Motor Power | Length | Height | Width |
| MM | MM | MM | MM | MM | MM | HP | Machine Diemention (MM) | |||
| VH4 20/06 | 2100 | 6 | 4 | 160 | 140 | 120 | 3 | 3950 | 1160 | 1080 |
| VH4 20/08 | 2100 | 8 | 6 | 190 | 170 | 150 | 5 | 3950 | 1160 | 1080 |
| VH4 20/10 | 2100 | 10 | 8 | 210 | 190 | 170 | 10 | 3950 | 1160 | 1080 |
| VH4 20/12 | 2100 | 12 | 10 | 230 | 210 | 190 | 10 | 4030 | 1275 | 1370 |
| VH4 20/16 | 2100 | 16 | 12 | 270 | 250 | 210 | 15 | 4180 | 1385 | 1440 |
| VH4 20/20 | 2100 | 20 | 16 | 300 | 270 | 230 | 20 | 4440 | 1630 | 1620 |
| VH4 20/25 | 2100 | 25 | 20 | 330 | 300 | 250 | 20 | 4250 | 1850 | 1800 |
| VH4 20/30 | 2100 | 30 | 25 | 360 | 330 | 270 | 25 | 4500 | 2000 | 1900 |
| VH4 20/40 | 2100 | 40 | 30 | 390 | 360 | 300 | 30 | 4900 | 2200 | 2000 |
| VH4 20/50 | 2100 | 50 | 40 | 430 | 390 | 330 | 40 | 5200 | 2500 | 2200 |
| VH4 25/06 | 2600 | 6 | 4 | 190 | 170 | 150 | 5 | 4450 | 1160 | 1080 |
| VH4 25/08 | 2600 | 8 | 6 | 210 | 190 | 170 | 10 | 4450 | 1160 | 1080 |
| VH4 25/10 | 2600 | 10 | 8 | 230 | 210 | 190 | 10 | 4530 | 1300 | 1370 |
| VH4 25/12 | 2600 | 12 | 10 | 270 | 250 | 210 | 15 | 4680 | 1350 | 1450 |
| VH4 25/16 | 2600 | 16 | 12 | 300 | 270 | 240 | 15 | 5000 | 1650 | 1650 |
| VH4 25/20 | 2600 | 20 | 16 | 330 | 300 | 250 | 20 | 5000 | 1850 | 1850 |
| VH4 25/25 | 2600 | 25 | 20 | 360 | 330 | 300 | 25 | 4900 | 1950 | 1850 |
| VH4 25/30 | 2600 | 30 | 25 | 390 | 360 | 330 | 30 | 5400 | 2150 | 2000 |
| VH4 25/40 | 2600 | 40 | 30 | 430 | 390 | 360 | 40 | 6000 | 2250 | 2200 |
| VH4 30/06 | 3100 | 6 | 4 | 210 | 190 | 170 | 7.5 | 5000 | 1200 | 1100 |
| VH4 30/08 | 3100 | 8 | 6 | 230 | 210 | 190 | 10 | 5100 | 1300 | 1400 |
| VH4 30/10 | 3100 | 10 | 8 | 270 | 250 | 210 | 10 | 5200 | 1400 | 1500 |
| VH4 30/12 | 3100 | 12 | 10 | 300 | 270 | 230 | 15 | 5500 | 1700 | 1700 |
| VH4 30/16 | 3100 | 16 | 12 | 330 | 300 | 240 | 20 | 5700 | 1900 | 1900 |
| VH4 30/20 | 3100 | 20 | 16 | 360 | 330 | 250 | 20 | 5700 | 1900 | 1900 |
| VH4 30/25 | 3100 | 25 | 20 | 390 | 360 | 300 | 25 | 5900 | 2000 | 2100 |
| VH4 30/30 | 3100 | 30 | 25 | 430 | 390 | 330 | 30 | 6000 | 2200 | 2300 |
| VH4 30/40 | 3100 | 40 | 30 | 460 | 420 | 360 | 40 | 6200 | 2450 | 2400 |
| VH4 30/50 | 3100 | 50 | 40 | 510 | 460 | 390 | 50 | 6400 | 2800 | 2500 |
| VH4 40/06 | 4100 | 6 | 4 | 270 | 250 | 210 | 7.5 | 6200 | 1400 | 1500 |
| VH4 40/08 | 4100 | 8 | 6 | 300 | 270 | 230 | 10 | 6300 | 1700 | 1700 |
| VH4 40/10 | 4100 | 10 | 8 | 330 | 300 | 240 | 10 | 6400 | 1900 | 1900 |
| VH4 40/12 | 4100 | 12 | 10 | 360 | 330 | 300 | 15 | 6500 | 1900 | 1900 |
| VH4 40/16 | 4100 | 16 | 12 | 390 | 360 | 330 | 20 | 7000 | 2000 | 2150 |
| VH4 40/20 | 4100 | 20 | 16 | 430 | 390 | 360 | 20 | 7200 | 2200 | 2200 |
| VH4 40/25 | 4100 | 25 | 20 | 460 | 420 | 390 | 25 | 7300 | 2500 | 2350 |
| VH4 40/30 | 4100 | 30 | 25 | 510 | 460 | 420 | 30 | 7500 | 2800 | 2500 |
Looking for "4 Roll Hydraulic Pre Pinch ype Plate Rolling Machine" ?
