Product Details
Voltage
440V
Application
Industrial
Automatic Grade
Automatic
Driven Type
Electric
Under crank shearing machine are drafted and plan through structural inspection technique for prominent performance, continuous and large-scale production, accurateness and high longevity.
Some of the unique features of these machines are-
- Rigid
- Interconnected in design with strong weld structure of MS plates
- Take complete load with least deflection.
A firm clutch is supplied for giving persistent strokes for production. Under Crank Shearing Machines, have four edged rectangular high quality high carbon high chromium (HCHC) knives for longer durability. Gunmetal bushes are available in all running mechanical parts. A strong mechanical back gauge and hand operated single shot lubrication system is also available in all the shearing machines as standard equipment.
Specifications
| MODEL | CUTTING CAP.IN MS LENGTH X THICKNESS | TABLE HEIGHT | TABLE WIDTH | FRONT GAUGE | BACK GAUGE | MOTOR (HP /RPM) | SIZE OF BLADE | OVER ALL DIMENSION | ||||
| LENGTH | WIDTH | THICKNESS | LENGTH | WIDTH | HEIGHT | |||||||
| VIUS - 1 | 1250 X 2 | 750 | 250 | 500 | 500 | 03/01/40 | 1270 | 60 | 14 | 2100 | 1900 | 1300 |
| VIUS - 2 | 1525 X 2 | 750 | 250 | 500 | 500 | 03/01/40 | 1550 | 60 | 14 | 2360 | 1900 | 1300 |
| VIUS - 3 | 2030 X 2 | 800 | 300 | 500 | 500 | 05/01/40 | 2050 | 60 | 14 | 2825 | 1900 | 1300 |
| VIUS - 4 | 2540 X 2 | 800 | 300 | 500 | 500 | 7.5 / 1440 | 2550 | 60 | 14 | 3325 | 1900 | 1300 |
| VIUS - 5 | 3125 X 2 | 800 | 300 | 500 | 500 | 10/01/40 | 3150 | 62 | 18 | 3190 | 1900 | 1300 |
| VIUS - 6 | 1250 X 4 | 800 | 300 | 600 | 600 | 05/01/40 | 1270 | 62 | 18 | 2300 | 2000 | 1350 |
| VIUS - 7 | 1525 X 4 | 800 | 300 | 600 | 600 | 05/01/40 | 1550 | 62 | 18 | 2550 | 2000 | 1350 |
| VIUS - 8 | 2030 X 4 | 800 | 300 | 600 | 600 | 7.5 / 1440 | 2050 | 62 | 18 | 3100 | 2000 | 1350 |
| VIUS - 9 | 2540 X 4 | 800 | 350 | 600 | 600 | 10/01/40 | 2540 | 75 | 18 | 3600 | 2000 | 1350 |
| VIUS - 10 | 3125 X 4 | 800 | 350 | 600 | 600 | 12.5 / 1440 | 3150 | 75 | 18 | 4200 | 2000 | 135 |
